Musique L-600
Laurehk Radio Mfg. Co.; Wayne, Mich.
- Country
- United States of America (USA)
- Manufacturer / Brand
- Laurehk Radio Mfg. Co.; Wayne, Mich.
- Year
- 1937 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 214998
-
- Brand: Musique
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 110 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- from Radiomuseum.org
- Model: Musique L-600 - Laurehk Radio Mfg. Co.; Wayne,
- Notes
- AM: 550 - 1500 kHz; Ballast tube L49B
- Mentioned in
- Rider's Perpetual, Volume 8 = 1937 and before (Misc. Page 8-5)
- Literature/Schematics (1)
- Ballast-Tube Handbook; Jacobi 1985
- Author
- Model page created by Harry Ducker. See "Data change" for further contributors.
