- Country
- Spain
- Manufacturer / Brand
- Lavis S.A., Labelson; Barcelona
- Year
- 1965/1966
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 238969
ABC Madrid, 21/09/1965, p.70
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Number of Transistors
- 15
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900/33400 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: 219 - Lavis S.A., Labelson;
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Lavis, S.A., 219
TV B/N 19" con sintonizador para VHF-UHF
Según normas CCIR 625 líneas. Bandas I, II, III IV y V (VHF-UHF).
Altavoz elíptico de 5" x 7" y redondo de 4"
- Price in first year of sale
- 19,880.00 ESP
- Mentioned in
- "50 Esquemas Comentados", Prof. J. V. De Abarrategui
- Literature/Schematics (1)
- ABC Madrid, 21/09/1965, p.70
- Literature/Schematics (2)
- Esquemario TV REDE, Tomo III, 1967
- Author
- Model page created by Carlos A. Pieroni-García. See "Data change" for further contributors.
