- Country
- Spain
- Manufacturer / Brand
- Lavis S.A., Labelson; Barcelona
- Year
- 1971
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 114078
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Line / Batteries (any type) / 125; 220 7 4 × 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Power out
- 1 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: T-921 - Lavis S.A., Labelson;
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 310 x 153 x 90 mm / 12.2 x 6 x 3.5 inch
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- Manufacturer Literature
- Author
- Model page created by Ramon Gancedo. See "Data change" for further contributors.
