Lizard RF
La Voce della Radio; Milano
- Country
- Italy
- Manufacturer / Brand
- La Voce della Radio; Milano
- Year
- 1965 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 177233
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Lizard RF - La Voce della Radio; Milano
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 530 x 270 x 280 mm / 20.9 x 10.6 x 11 inch
- Notes
- Ricezione audio dei canali TV.
Tastiera gigante a 9 posizioni.
Mobile in legno con frontale in plastica.
Giradischi a 4 velocità.
- Net weight (2.2 lb = 1 kg)
- 12 kg / 26 lb 6.9 oz (26.432 lb)
- Price in first year of sale
- 59,000.00 ITL
- Mentioned in
- Catalogo ANIE 1965-66
- Author
- Model page created by Eduard Abfalterer. See "Data change" for further contributors.
