Utility Scope LBO-3B
Leader Electronics Corp.; Yokohama
- Country
- Japan
- Manufacturer / Brand
- Leader Electronics Corp.; Yokohama
- Year
- 1963
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 101665
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 100; 115; 230 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Utility Scope LBO-3B - Leader Electronics Corp.;
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 150 x 225 x 300 mm / 5.9 x 8.9 x 11.8 inch
- Notes
- The LBO3B is a 3" DC Oscilloscope: DC-2 MHz sensivity: 25 mV rms/cm. The leaflet shows a wrong CRT with designation 3KPLF instead of 3KP1F. See also the Oscilloscope LBO-3A
- Net weight (2.2 lb = 1 kg)
- 6.8 kg / 14 lb 15.6 oz (14.978 lb)
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Hugo Sneyers. See "Data change" for further contributors.
