• Country
• Germany

• Manufacturer / Brand
• Lectron GmbH; Frankfurt/M.

• Year
• 2006

• Category
• Teaching aids-material

• Radiomuseum.org ID
• 201226

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• BF245 2N3702 SFH350 AC125 IRFZ24N IRF9Z24N CD4047 CD4046 CD4520 CD4520 CD4070 CD4070 CD4013 CD4013 CA3140 CA3140 CNY17

• Main principle
• PLL, Phase-locked loop

• Wave bands
• - without

• Power type and voltage
• Powered by external power supply or a main unit. / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Lectron Ausbau-System PLL-Technik 1015 - Lectron GmbH; Frankfurt/M.

• Notes
• 32 magnetische Bausteine für 48 Versuche zum Thema "PLL-Technik".
  Voraussetzung: Lectron Digitaltechnik 1011 oder Lectron Start-System 1003 + Lectron Ausbau-System 1004 + Lectron Ausbau-System Digitaltechnik 1007.

• Price in first year of sale
• 184.00 EUR

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.

• Other Models

• Here you find 41 models, 40 with images and 34 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Lectron GmbH; Frankfurt/M.
