Starvox SV-2620

Lee Wah Electronics Ltd.; Hong Kong

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 208799

 Technical Specifications

  • Number of Transistors
  • 20
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player; Radio with other functions
  • Power type and voltage
  • Storage and/or dry batteries / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Starvox SV-2620 - Lee Wah Electronics Ltd.; Hong
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 180 x 140 x 44 mm / 7.1 x 5.5 x 1.7 inch
  • Notes

  • Starvox SV-2620 Micro Computer AM/FM/MPX Stereo Car Radio Cassette Player, DC 12V positive, 1 Quartz, 14 IC´s, 3 FET, 26 Dioden, 7 LED.

  • Net weight (2.2 lb = 1 kg)
  • 1.6 kg / 3 lb 8.4 oz (3.524 lb)
  • Author
  • Model page created by Eckhard Wegner. See "Data change" for further contributors.
