TM653/3
Leibovic, A.; Riga, LV
- Country
- Latvia (Latvia, Riga)
- Manufacturer / Brand
- Leibovic, A.; Riga, LV
- Year
- 1939 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 124536
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 469 kHz; 1 AF stage(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110/220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Power out
- 2 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: TM653/3 - Leibovic, A.; Riga, LV
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 580 x 290 x 250 mm / 22.8 x 11.4 x 9.8 inch
- Source of data
- -- Collector info (Sammler)
