Irene Type 131 93024

Leinetal GmbH & Co. KG, Kreiensen

Data
Forum
Pictures
Collections

  • Year
  • 1962/1963 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 143312

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110 -117; 127; 220; 240 - 250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 4.5 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Irene Type 131 93024 - Leinetal GmbH & Co. KG,
  • Shape
  • Console with Push Buttons.
  • Dimensions (WHD)
  • 720 x 610 x 390 mm / 28.3 x 24 x 15.4 inch
  • Notes

  • Radio entspricht Schaub Lorenz Goldy 30 Plattenwechsler ist ELAC Miracord 16 (PW 16)

    Abmessungen ohne Standfüsse

  • Source of data
  • - - Data from my own collection
  • Author
  • Model page created by Günter Denoth. See "Data change" for further contributors.
