• Country
• Germany

• Manufacturer / Brand
• Lembeck & Co.(Lembeck-Radio)

• Year
• 1952/1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 15803

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• EF80 EC92 ECH81 EF85 EM4 EF42 EABC80 ECC40 EL41 EL41

• Main principle
• Superheterodyne (common); ZF/IF 466 kHz

• Tuned circuits
• 8 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Atlantis W1030 - Lembeck & Co.Lembeck-Radio

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 670 x 415 x 350 mm / 26.4 x 16.3 x 13.8 inch

• Notes
• variable Bandbreite; 4× KW.

• Net weight (2.2 lb = 1 kg)
• 20 kg / 44 lb 0.8 oz (44.053 lb)

• Price in first year of sale
• 498.00 DM

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Kat.d.Rundf.GrossH.1952/53 / Radiokatalog Band 2, Ernst Erb
