Sesselsuper Atlantis 10 Röhren
Lembeck & Co.(Lembeck-Radio)
- Country
- Germany
- Manufacturer / Brand
- Lembeck & Co.(Lembeck-Radio)
- Year
- 1952/1953
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 15806
- Number of Tubes
- 10
- Main principle
- Superheterodyne (common); ZF/IF 466/10700 kHz
- Tuned circuits
- 8 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sesselsuper Atlantis [10 Röhren] - Lembeck & Co.Lembeck-Radio
- Shape
- Console: Chairside Radio.
- Dimensions (WHD)
- 1030 x 720 x 500 mm / 40.6 x 28.3 x 19.7 inch
- Notes
-
Rundfunk-Chassis = Atlantis W52.
Siehe eines der US-Vorbilder mit Abbildung für die Idee Sesselsuper:
Modell 5J247 von Zenith Radio Corp.
Es gab in den USA einige Sessel-Super-Modelle.
- Net weight (2.2 lb = 1 kg)
- 48 kg / 105 lb 11.6 oz (105.727 lb)
- Price in first year of sale
- 985.00 DM
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Kat.d.Rundf.GrossH.1952/53 / Radiokatalog Band 2, Ernst Erb
- Other Models
-
Here you find 71 models, 46 with images and 23 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Lembeck & Co.(Lembeck-Radio)
Collections
The model Sesselsuper Atlantis is part of the collections of the following members.
Forum contributions about this model: Lembeck & Co.Lembeck: Sesselsuper Atlantis
Threads: 1 | Posts: 2
Der Sesselsuper ist ausgestattet mit einem perm.-magn. Lautsprecher, ca. 20cm Durchmesser.
Das Phonochassis ist von DUAL, Typ 260. System el.-dynamisch.
Das Phonochassis ist von DUAL, Typ 260. System el.-dynamisch.
Hans-Werner Ellerbrock, 18.Oct.07
