Sesselsuper Atlantis 8 Röhren
Lembeck & Co.(Lembeck-Radio)
- Country
- Germany
- Manufacturer / Brand
- Lembeck & Co.(Lembeck-Radio)
- Year
- 1952 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 193519
Plattenfach für 30Stück 30cm-Platten
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common)
- Wave bands
- Ready for FM, has Broadcast, Long Wave, several Short Wave.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sesselsuper Atlantis [8 Röhren] - Lembeck & Co.Lembeck-Radio
- Shape
- Console: Chairside Radio.
- Dimensions (WHD)
- 855 x 665 x 460 mm / 33.7 x 26.2 x 18.1 inch
- Notes
- Das Phonochassis ist von DUAL, Typ 260. System el.-dynamisch. Skala mit UKW-Teilung, UKW-Drucktaste und Sockel für Zusatzteil sind vorhanden. Das schwenkbare Plattenfach kann 30 Schellackplatten mit 25cm oder 30cm Durchmesser aufnehmen.
- Author
- Model page created by Hans-Werner Ellerbrock. See "Data change" for further contributors.
