• Country
• Soviet Union

• Manufacturer / Brand
• Leningrad Kozitsky Works

• Year
• 1951

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 83969

• • alternative name: Radiotelegraf Works

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• 6Ж3П 6Н1П 6Ж3П 6Ж3П 6Ж3П 6П9 6Ж3П 6Ж3П 6Ж3П 6Ж3П 6П9 6Н1П 6П1П 31ЛК2Б 6Н1П Г-807 1Ц1С 6Ц4П 5Ц3С

• Number of Transistors

• Semiconductors
• ДГ-Ц12 ДГ-Ц14 ДГ-Ц13 ДГ-Ц13

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Avangard {АВАНГАРД} TL1 - Leningrad Kozitsky Works

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 445 x 535 x 410 mm / 17.5 x 21.1 x 16.1 inch

• Notes
• Picture tube 31LK2B; 220 Watts power consumption, 3-channel-Soviet VHF-Low-Band-I Standard tuner; Loudspeaker was installed under hinged cover.
  Bildröhre 31LK2B; 220 Watt Leistungsaufnahme; 3-Kanal-Band-1 OIRT Tuner; Lautsprecher ist unter aufklappbaren Gerätedeckel montiert.

• Net weight (2.2 lb = 1 kg)
• 35 kg / 77 lb 1.5 oz (77.093 lb)

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
