Renas LR 8

LESA ; Milano

Data
Forum
Pictures
Collections

  • Year
  • 1963 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 282502

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
  • Power out
  • 2.5 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Renas LR 8 - LESA ; Milano
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 310 x 185 x 270 mm / 12.2 x 7.3 x 10.6 inch
  • Notes

  • Registratore/ripoduttore a bobina.

    Risposta in frequenza: velocità 9,6 cm/sec. 50-12000 Hz - velocità 4,7 cm/sec. 50-7000 Hz - velocità 2,4 cm/sec.

    Ingresso fono/radio : 50 mV/47Kohm.

    Uscita cuffia e microfono esterno - Raddrizzatore al selenio BPH 250 -90MA.




  • Net weight (2.2 lb = 1 kg)
  • 8.5 kg / 18 lb 11.6 oz (18.722 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
