R.C. Oscillator TG150M
Levell Electronics Ltd ; Barnet ,Herts
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Levell Electronics Ltd ; Barnet ,Herts
- Year
- 1970 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 213382
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 5
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / 2x 9 Volt
- Loudspeaker
- - - No sound reproduction output.
- from Radiomuseum.org
- Model: R.C. Oscillator TG150M - Levell Electronics Ltd ;
- Shape
- Tablemodel, with any shape - general.
- Notes
- Levell Electronics R.C. oscillator model TG150M. Sine wave output only. Output meter with Volts and dB scales.
- Source of data
- -- Original-techn. papers.
