118 x ED. 4B
Link Radio Co.; New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Link Radio Co.; New York (NY)
- Year
- 1947 ??
- Category
- Commercial Receiver (may include amateur bands)
- Radiomuseum.org ID
- 294508
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 262 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz; 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 118 x ED. 4B - Link Radio Co.; New York NY
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 16.5 x 9.5 x 8 inch / 419 x 241 x 203 mm
- Notes
-
This is a single frequency receiver with frequency set by crystal. The radio pictured was used by the Texas Forest Service on 2226KHz. There is a 500 ohm output that may have been used to activate tone sensitive indicators on a map. Tone signals may have been sent from fire observation towers to a central facitlity where this radio was located.
- Net weight (2.2 lb = 1 kg)
- 18 lb (18 lb 0 oz) / 8.172 kg
- Author
- Model page created by Jay Kinnard. See "Data change" for further contributors.
