- Country
- Great Britain (UK)
- Manufacturer / Brand
- Lissen Ltd.; London and Richmond, Surrey
- Year
- 1934/1935
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 223665
- Number of Tubes
- 3
- Main principle
- TRF with regeneration
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- Magnetic loudspeaker (reed) generic.
- Material
- Wooden case
- from Radiomuseum.org
- Model: 8100 - Lissen Ltd.; London and
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 13.75 x 17.75 x 8 inch / 349 x 451 x 203 mm
- Notes
- Two R.C. coupled stages. Outside Aerial
- Price in first year of sale
- 5.00 GBP
- Author
- Model page created by Michael Watterson. See "Data change" for further contributors.
- Other Models
-
Here you find 159 models, 124 with images and 58 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Lissen Ltd.; London and Richmond, Surrey
