PH-41A

Lloyd's Electronics; Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1965 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 134887

 Technical Specifications

  • Number of Transistors
  • 5
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Dry Batteries / D: 4 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
  • Power out
  • 0.8 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: PH-41A - Lloyd's Electronics; Chicago,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 11.13 x 2.25 x 7 inch / 283 x 57 x 178 mm
  • Notes

  • Lloyd's PH-41A; Record player for 33 1/3 & 45 rpm disks.

    This unit has a particular mode for disk speed: A rubber wheel turns the disk directly. The disk holder can be moved into 2 positions more or less distant from the wheel. Shorter distance 45 rpm, greater distance 33 rpm.

  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
