F 654 electronic 52356
Loewe-(Opta); Deutschland
- Country
- Germany
- Manufacturer / Brand
- Loewe-(Opta); Deutschland
- Year
- 1972
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 288860
-
- alternative name: Löwe Radio
Eltropa Katalog 72/3
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Number of Transistors
- 15
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: F 654 electronic 52356 - Loewe-Opta; Deutschland
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 700 x 485 x 420 mm / 27.6 x 19.1 x 16.5 inch
- Notes
-
Schwarz-weiß-Tischgerät Loewe Opta F 654 electronic, 61-cm-Rechteck-Bildröhre, 7-fache vollelektronische Programmwechsel-Automatik, 2 integrierte Schaltungen, Edelholzgehäuse nussbaumfarben oder Schleiflack weiß. Info: Eltropa-Exklusiv-Gerät
- Mentioned in
- -- Original prospect or advert (Eltropa Katalog 72/3)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
