• Country
• Germany

• Manufacturer / Brand
• Opta-(Spezial) (siehe auch Loewe-Opta)

• Year
• 1954/1955

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 80559

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• EC92 EC92 EF85 ECH81 EM34 EF41 EABC80 EC92 EL84 EL84

• Main principle
• Superhet with RF-stage; ZF/IF 468/10700 kHz

• Tuned circuits
• 9 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 15 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Rheingold 5055W Plastikton [15 Watt] - Opta-Spezial siehe auch Loewe-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 650 x 425 x 300 mm / 25.6 x 16.7 x 11.8 inch

• Notes
• "Plastikton" bedeutet soviel wie 3D-Klang.

• Net weight (2.2 lb = 1 kg)
• 16 kg / 35 lb 3.9 oz (35.242 lb)

• Source of data
• HdB d.Rdf-& Ferns-GrH 1954/55

• Author
• Model page created by Ernst Erb. See "Data change" for further contributors.

• Other Models

• Here you find 49 models, 43 with images and 26 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
