• Country
• Germany

• Manufacturer / Brand
• Loewe-(Opta); Deutschland

• Year
• 1954/1955

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 96760

• • alternative name: Löwe Radio

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 15

• Valves / Tubes
• PCC84 PCC85 EF80 EF80 EF80 PCF80 EF80 PCL81 PCF80 ECC82 PL81 PY81 EY86 PCL81 MW43-64

• Number of Transistors

• Semiconductors
• DS180 DS181z Tr.Gl.=Metal-rectif.

• Main principle
• Superhet with RF-stage; ZF/IF 28750/550 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• AC/DC-set / 200; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Optalux 609 - Loewe-Opta; Deutschland

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 520 x 490 x 430 mm / 20.5 x 19.3 x 16.9 inch

• Notes
• 43-cm-Bildröhre; 10 VHF-Kanäle + 2 Reserve, Einbau UHF-Converter vorgesehen.

• Net weight (2.2 lb = 1 kg)
• 20 kg / 44 lb 0.8 oz (44.053 lb)

• Source of data
• HdB d.Rdf-& Ferns-GrH 1954/55

• Mentioned in
• Rundfunk- Phono- Fernseh-Katalog 1954/55 S.119 (Thiele)

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
