Sensotronic CT5025 Color Ch= C5000, Art.Nr. 55442
Loewe-(Opta); Deutschland
- Country
- Germany
- Manufacturer / Brand
- Loewe-(Opta); Deutschland
- Year
- 1975 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 339721
-
- alternative name: Löwe Radio
- Number of Tubes
- 1
- Valves / Tubes
- A66-500X
- Number of Transistors
- 26
- Semiconductors
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sensotronic CT5025 Color Ch= C5000, Art.Nr. 55442 - Loewe-Opta; Deutschland
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 755 x 520 x 465 mm / 29.7 x 20.5 x 18.3 inch
- Notes
-
Loewe Sensotronic CT5025 Color ist ein 66 cm Farbfernsehempfänger mit inline-Bildröhre (Schlitzmaske). 12 Sensorfelder für die Programmwahl im VHF Band I/III und UHF Band IV/V Bereichen, LED-Programmanzeige.
Zusätzliche Bestückung: 13 ICs, 116 Dioden und Gleichrichter, 4 Thyristoren.
FTZ-Prüf-Nr. Z302C
- Net weight (2.2 lb = 1 kg)
- 39 kg / 85 lb 14.4 oz (85.903 lb)
- Author
- Model page created by Paolo Tarantino. See "Data change" for further contributors.
