• Country
• Germany

• Manufacturer / Brand
• Loewe-(Opta); Deutschland

• Year
• 1965–1967

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 26095

• • alternative name: Löwe Radio

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECC85 ECH81 EF89 EAF801 EMM803

• Number of Transistors
• 22

• Semiconductors
• AC151r AC121 AF138 AC127 AC132 AD150 AD133 AF118 AF126 BC108

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 8 AM circuit(s)     12 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo-Luxus-Steuergerät LO50TR Typ 62091 - Loewe-Opta; Deutschland

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 600 x 240 x 265 mm / 23.6 x 9.4 x 10.4 inch

• Notes

• Transistoren teilweise mehrfach vorhanden.
  Abschaltbare Ferritantenne,
  Stereo-Decoder eingebaut,
  Stereo-NF-Verstärker mit 2 Endstufen je 20 W.
  Dazugehörig: 2 LS-Boxen LO50 (nicht im Lieferumfang).

• Net weight (2.2 lb = 1 kg)
• 10.5 kg / 23 lb 2 oz (23.128 lb)

• External source of data
• erb

• Source of data
• Handbuch VDRG 1965/1966

• Literature/Schematics (1)
• -- Original-techn. papers.
