• Country
• Germany

• Manufacturer / Brand
• Loewe-(Opta); Deutschland

• Year
• 1964/1965

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 25822

• • alternative name: Löwe Radio

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EAF801 ECC83 EMM803 ELL80

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Verona-Stereo 52 271 - Loewe-Opta; Deutschland

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 1050 x 720 x 360 mm / 41.3 x 28.3 x 14.2 inch

• Notes
• Truhen-Chassis 52870; Stereo-Decoder (AF118, 2× AF126) eingebaut; Stereo-NF-Verstärker mit 2 Endstufen je 4 W;
  Phono-Chassis = Philips AG1025; Tonbandgerät nachträglich einsetzbar.

• Net weight (2.2 lb = 1 kg)
• 33 kg / 72 lb 11 oz (72.687 lb)

• Price in first year of sale
• 1,058.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1964/1965
