- Country
- Germany
- Manufacturer / Brand
- Lorenz; Berlin, Zuffenhausen u.a.
- Year
- 1938–1940
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 3048
-
- Brand: SEL
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
Aus Ebay vom Verkäufer tubenarr
- Number of Tubes
- 5
- Main principle
- Audio-Amplification; 3 AF stage(s)
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 235; 250 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 10 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: LVA10 - Lorenz; Berlin, Zuffenhausen u
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 340 x 210 x 200 mm / 13.4 x 8.3 x 7.9 inch
- Notes
- Eingangs-Steuerspannung: 0,1 V; Ausgangs-Impedanzen: 500 und 1000 Ohm.
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Price in first year of sale
- 431.00 RM
- Source of data
- Handbuch WDRG 1938 / Radiokatalog Band 1, Ernst Erb
- Circuit diagram reference
- Röhren in FS-Bestückungstabellen
