LVA. 50 M
Lorenz; Berlin, Zuffenhausen u.a.
- Country
- Germany
- Manufacturer / Brand
- Lorenz; Berlin, Zuffenhausen u.a.
- Year
- 1936–1940
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 3036
-
- Brand: SEL
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
By courtesy of member 6505.
Q: Katalog RF-Großhandel '38
- Number of Tubes
- 6
- Main principle
- Audio-Amplification; 3 AF stage(s)
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 235; 250 Volt
- Loudspeaker
- - For headphones or amp.
- Power out
- 50 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: LVA. 50 M - Lorenz; Berlin, Zuffenhausen u
- Dimensions (WHD)
- 470 x 250 x 250 mm / 18.5 x 9.8 x 9.8 inch
- Notes
- Ausgangs-Anschluß-Impedanzen: 100/140/200 Ohm.
- Net weight (2.2 lb = 1 kg)
- 19.5 kg / 42 lb 15.2 oz (42.952 lb)
- Price in first year of sale
- 1,050.00 RM
- Source of data
- HandB.d.d.Rundfunk-Handels 1936/37 / Radiokatalog Band 1, Ernst Erb
- Circuit diagram reference
- Röhren in FS-Bestückungstabellen
