4-Röhren Neutrodyne
Lumophon, Bruckner & Stark, Nürnberg
- Country
- Germany
- Manufacturer / Brand
- Lumophon, Bruckner & Stark, Nürnberg
- Year
- 1927 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 231529
-
- Brand: Lumeta
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Valves / Tubes
- Main principle
- TRF with regeneration; 2 AF stage(s); Neutrodyne
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: 4-Röhren Neutrodyne - Lumophon, Bruckner & Stark,
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 630 x 290 x 280 mm / 24.8 x 11.4 x 11 inch
- Notes
-
Lang- und Mittelwelle in 4 Bereichen:
150 - 450 m
250 - 600 m
700 - 2000 m
1500 - 3000 m.
- Author
- Model page created by Hans-Ulrich Rossius. See "Data change" for further contributors.
