• Country
• Japan

• Manufacturer / Brand
• Luxman, Lux Corp.; Kinsuido of Osaka

• Year
• 1990 ??

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 275445

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 120 W (220 W max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Integrated Amplifier LV-104U - Luxman, Lux Corp.; Kinsuido of

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 438 x 148 x 353 mm / 17.2 x 5.8 x 13.9 inch

• Notes

• Luxman Stereo Integrated Amplifier Model LV-104U.
  Power output:
  60 Watts per channel into 8Ω (stereo)
  80 Watts per channel into 6Ω (stereo)
  Frequency response: 1Hz to 150kHz
  Total harmonic distortion: 0.25%
  Input sensitivity: 0.14mV (MC), 2mV (MM), 150mV (line)
  Signal to noise ratio: 70dB (MC), 90dB (MM), 110dB (line)
  Speaker load impedance: 4Ω (minimum)
  Inputs: Phono MM, Phono MC, Tuner, CD, Tape, AV (audio)
  Tone Controls:
  Bass 100Hz +/-5dB
  Treble (10000Hz) +/-6dB
  Loudness - 100Hz +6dB, 10000Hz +5dB


• Net weight (2.2 lb = 1 kg)
• 10.2 kg / 22 lb 7.5 oz (22.467 lb)

• Mentioned in
• - - Manufacturers Literature (Instruction/Owners Manual)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
