Magestic Preamplificador Mezclador 6 canales M-1017
Magestico (Magnedine, Radio Pujals); Barcelona
- Country
- Spain
- Manufacturer / Brand
- Magestico (Magnedine, Radio Pujals); Barcelona
- Year
- 1970 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 313055
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Semiconductors
- unknown_tr B30C250
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Magestic Preamplificador Mezclador 6 canales M-1017 - Magestico Magnedine, Radio
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 320 x 20 x 85 mm / 12.6 x 0.8 x 3.3 inch
- Notes
-
El esquema muestra 7 transistores porque faltan dos entradas, para los canales V y VI, idénticas a la representada en el canal IV.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
