• Country
• Italy

• Manufacturer / Brand
• Magnadyne Radio; Torino

• Year
• 1948 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 120907

• Number of Tubes
• 6

• Valves / Tubes
• 6TE8GT 6SK7GT 6SQ7GT 6E5GT 6V6GT 5Y3GT

• Main principle
• Superheterodyne (common); ZF/IF 471 kHz

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: SV85C - Magnadyne Radio; Torino

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 605 x 310 x 200 mm / 23.8 x 12.2 x 7.9 inch

• Notes
• Gamme d'onda: Onde medie e 6 gamme di onde corte

• Mentioned in
• -- Collector info (Sammler)

• Other Models

• Here you find 355 models, 274 with images and 256 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Magnadyne Radio; Torino
