D1066 /17
Philips Magnavox (brand); Knoxville, TN
- Country
- United States of America (USA)
- Manufacturer / Brand
- Philips Magnavox (brand); Knoxville, TN
- Year
- 1982 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 231102
Etsy Shop IndustrialJack Item No.: 112132091
Etsy Shop IndustrialJack Item No.: 112132091
Etsy Shop IndustrialJack Item No.: 112132091
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / AA: 2 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: D1066 /17 - Philips Magnavox brand;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 2.75 x 4 x 1.5 inch / 70 x 102 x 38 mm
- Notes
-
AM band only. Wrist strap.
Marketed by N.A.P. Consumer Electronics Corporation (Knoxville, TN) which incorporated in 1981 and dissolved in 1989.
See also Philips D1066.
Made in India
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
