Chassis V23A-02AA (23 Series)
Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN
- Country
- United States of America (USA)
- Manufacturer / Brand
- Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN
- Year
- 1958 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 321974
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 23
- Valves / Tubes
- 6BC8 6U8 6BZ6 6BZ6 6CB6 6AW8 6AN8 6AU6 6AU6 6T8 6DG6GT or 6W6GT 6SN7GTB 6S4 6SN7GTB 6DQ6 6AX4GT 1B3GT 5U4GB 24YP4 12AX7 6V6GT 6V6GT 5Y3GT
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Chassis V23A-02AA - Magnavox Co., Commercial
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Magnavox Chassis V23A-02AA is a 24" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with VHF tuner 700541-5, audio amplifier AMP-135BB and picture tube 24YP4.
