• Country
• United States of America (USA)

• Manufacturer / Brand
• Magnavox Co., Commercial Wireless and Development Co.; San Francisco, later Fort Waye, IN

• Year
• 1957 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 316259

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• Superhet with RF-stage

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: Ch= U19-02BB - Magnavox Co., Commercial

• Mentioned in
• Photofact Folder, Howard W. SAMS (Set 377 Folder 1 Prduction Changes Bulletin 192 dated 11-57)

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 360 Folder 6 dated 1956)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 387 Production Changes Bulletin 200 dated 2-58)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
