• Country
• United States of America (USA)

• Manufacturer / Brand
• Maguire Industries, Inc.

• Year
• 1947 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 46474

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: ARC-1 - Maguire Industries, Inc.

• Shape
• Chassis only or for «building in»

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 15 = 1947 and before

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS
