- Country
- United States of America (USA)
- Manufacturer / Brand
- Marantz (Sound United LLC); Vista, CA
- Year
- 1974 ?
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 150191
Marantz Prospektbild
Prospekt 1976
Marantz Prospekt
Speakers terminal changed, not original.
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- 2 Loudspeakers / Ø 8 inch = 20.3 cm
- Power out
- 15 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 4G - Marantz Sound United LLC;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 285 x 485 x 235 mm / 11.2 x 19.1 x 9.3 inch
- Notes
-
2-Weg-Regalbox mit 15/40 Watt Nenn-/Musik-Belastbarkeit (IHF).
1 TMT 180mm, 1 HT 45mm.Im Katalog der Firma Bolex GmbH wurden die Maße mit (BHT) 290 x 490 x 220mm und das Nettogewicht der Box mit 9,0 Kg angegeben.
- Net weight (2.2 lb = 1 kg)
- 6.1 kg / 13 lb 7 oz (13.436 lb)
- Source of data
- -- Original prospect or advert
- Literature/Schematics (1)
- Marantz Lautsprecher + Kopfhörer (deutsch) Bolex GmbH 874
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
