Auto Return/Synchro Drive TT-120

Marantz (Sound United LLC); Vista, CA

Data
Forum
Pictures
Collections

  • Year
  • 1985 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 351776

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Auto Return/Synchro Drive TT-120 - Marantz Sound United LLC;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 416 x 125 x 390 mm / 16.4 x 4.9 x 15.4 inch
  • Notes

  • Wow and flutter - less than 0.09%
    WRMS - less than 0.06%
    Rumble -
    DIN A - lower than -43dB
    DIN B - lower than -65dB
    tracking error - smaller than 0.9'/cm



    Power supply variants:
    N - 220V/50Hz
    E - 110/220V/50Hz
    T - 240V/50Hz UK only
    U - 120V/60Hz
    A - 240V/50Hz



  • Net weight (2.2 lb = 1 kg)
  • 4.250 kg / 9 lb 5.8 oz (9.361 lb)
  • Author
  • Model page created by Bartosz Szwed. See "Data change" for further contributors.
