Professional Cassette Recorder C-204

Superscope, Geneva IL

Data
Forum
Pictures
Collections

  • Year
  • 1978 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 143574
    • alternative name: Superscope, Chatsworth

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Remote Control (with wire or wireless)
  • Power type and voltage
  • Line plus power jack, mostly with battery or storage battery / 110; 120; 220; 240 / D: 4 x 1.5 / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 1.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Professional Cassette Recorder C-204 - Superscope, Geneva IL
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 293 x 82 x 195 mm / 11.5 x 3.2 x 7.7 inch
  • Notes

  • A portable professional cassette recorder labelled Superscope C-204 by Marantz, powered by AC mains, batteries or 6 volt rechargeable power pack. Monaural, servo control motor, permalloy heads, tape counter, built-in condenser microphone and a loudspeaker, VU meter for recording level and battery condition, variable speed control, speaker monitor switch, black transport case known. Jacks for external microphone, remote, aux input, line output and external loudspeaker, DIN socket for rec/play, 9V DC input.

    Versions/Power Requirements
    USA & Canada  /  120V AC 60Hz
    Europe  /  240/220/200/110V AC 50Hz
    DC:  /    Four "D" cell batteries
                6 volt Rechargeable pack : Model RBC-1

    Power consumption: 7 watts

    Semiconductors: Transistors 1, FET 1, Diodes 8, ICs 3

    Made in Taiwan

  • Net weight (2.2 lb = 1 kg)
  • 2.8 kg / 6 lb 2.7 oz (6.167 lb)
  • Source of data
  • -- Collector info (Sammler)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Service Manual C-204 dated December 1978)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
