• Year
  • 1935 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 245775

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 125 kHz
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 23 cm = 9.1 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 264 - Marconi Co. Marconiphone,
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Author
  • Model page created by Clive Forder. See "Data change" for further contributors.
