• Country
• Spain

• Manufacturer / Brand
• Marconi Española S.A. (Telmar); Villaverde

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 155500

• Number of Tubes
• 5

• Valves / Tubes
• UCH42 UAF42 UAF42 UL41 UY42

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Power out
• 2.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: P-50 - Marconi Española S.A. Telmar;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 370 x 250 x 180 mm / 14.6 x 9.8 x 7.1 inch

• Literature/Schematics (1)
• Anuncio La Vanguardia Española 29 Abril 1950

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
