• Country
• Spain

• Manufacturer / Brand
• Marconi Española S.A. (Telmar); Villaverde

• Year
• 1959 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 140290

• Number of Tubes
• 5

• Valves / Tubes
• UCH81 12BA6 12AT6 50C5 35W4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: UM2110 - Marconi Española S.A. Telmar;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 400 x 230 x 200 mm / 15.7 x 9.1 x 7.9 inch

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by Diego Fernandez-Fernandez. See "Data change" for further contributors.

• Other Models

• Here you find 192 models, 149 with images and 95 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Marconi Española S.A. (Telmar); Villaverde
