Air Core Choke Coil

Marconi's Wireless Telegraph Co. Ltd.

Data
Forum
Pictures
Collections

  • Year
  • 1914/1915
  • Category
  • Radio part (not a module)
  • Radiomuseum.org ID
  • 340895

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Air Core Choke Coil - Marconi's Wireless Telegraph
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Dimensions (WHD)
  • 12 x 6.25 x 4 inch / 305 x 159 x 102 mm
  • Notes

  • The function of the choke coil, is to prevent the high frequency condenser discharge current from surging back into the low frequency circuit, without interferring in any way with the low frequency condenser charging circuit.

    Used in the Marconi 1 1/2 K.W. Plain Discharger ship transmitting set.

  • Mentioned in
  • -- Original-techn. papers. (1915 Handbook of Technical Instruction for Wireless Telegraphers by Hawkhead and Dowsett)
  • Author
  • Model page created by Alan Larsen. See "Data change" for further contributors.
