• Country
• Great Britain (UK)

• Manufacturer / Brand
• Marconi Instruments, Marconi-Ekco (MI, MEI)

• Year
• 1969

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 82805

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 14

• Valves / Tubes
• 6AK5 6AK5 EF86 6AK5 6AU6 6AK5 12AT7 6AK5 0A2 6AK5 5Z4G 6AK5 12AT7 5651 6AL5 6AK5

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100-150,200-250 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Signal Generator TF 995B/5 - Marconi Instruments, Marconi-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 460 x 330 x 220 mm / 18.1 x 13 x 8.7 inch

• Notes
• AM/FM Signal Generator 0,2 MHz - 220 MHz 0,1 µV - 200 mV; BNC-connector.

• Net weight (2.2 lb = 1 kg)
• 18 kg / 39 lb 10.4 oz (39.648 lb)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
