- Country
- Italy
- Manufacturer / Brand
- Marelli (Radiomarelli); Sesto San Giovanni (MI)
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 337731
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 100-220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Power out
- 3 W (max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 9A75L - Marelli Radiomarelli; Sesto
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 400 x 360 x 230 mm / 15.7 x 14.2 x 9.1 inch
- Mentioned in
- Schemario Radioricevitori e Televisori Marelli 1963
- Author
- Model page created by Giuseppe Feniello. See "Data change" for further contributors.
