Arione Tipo 20

• Country
• Italy

• Manufacturer / Brand
• Marelli (Radiomarelli); Sesto San Giovanni (MI)

• Year
• 1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 73115

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 78 75 41 80

• Main principle
• Superheterodyne (common); ZF/IF 456 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Wave Bands given in the notes.

• Details
• Visual Tuning Indicator pre Eye

• Power type and voltage
• Alternating Current supply (AC) / 110; 160; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Arione Tipo 20 - Marelli Radiomarelli; Sesto

• Shape
• Console, Highboy (legs > 50 %).

• Dimensions (WHD)
• 550 x 900 x 330 mm / 21.7 x 35.4 x 13 inch

• Notes

• Chassis "Tipo 20".

  Tre gamme d'onda.
  Strumento indicatore di sintonia. Controllo di tono. Ingresso Fono.

• Price in first year of sale
• 1,400.00 ITL

• Source of data
• Guida Pratica Antique Radio (1) 1999

• Mentioned in
• La moderna Supereterodina, Ravalico, 1938 (pag. 371)

• Literature/Schematics (1)
• -- Schematic (Schemario degli Apparecchi Radio. D.E. Ravalico – Hoepli – 1944.)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
