Musagete Junior tipo 30 soprammobile
Marelli (Radiomarelli); Sesto San Giovanni (MI)
- Country
- Italy
- Manufacturer / Brand
- Marelli (Radiomarelli); Sesto San Giovanni (MI)
- Year
- 1931–1933 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 355225
- Number of Tubes
- 5
- Valves / Tubes
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); Anode bend detection
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 25 cm = 9.8 inch
- Power out
- 3 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Musagete Junior tipo 30 [soprammobile] - Marelli Radiomarelli; Sesto
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 570.5 x 500.5 x 330 mm / 22.5 x 19.7 x 13 inch
- Notes
-
Vedi anche Marelli Musagete Junior 30 (console)
- Net weight (2.2 lb = 1 kg)
- 25 kg / 55 lb 1.1 oz (55.066 lb)
- Price in first year of sale
- 1,480.00 ITL
- Author
- Model page created by Antonio Varrica. See "Data change" for further contributors.
