• Country
• Italy

• Manufacturer / Brand
• Marelli (Radiomarelli); Sesto San Giovanni (MI)

• Year
• 1971 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 280478

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• AF170 AF172 AF172 AC191 AC141 AC141 AC142

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 125; 220V Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 1.8 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: RD 329 - Marelli Radiomarelli; Sesto

• Dimensions (WHD)
• 295 x 114 x 110 mm / 11.6 x 4.5 x 4.3 inch

• Notes

• Altoparlante ellittico 8 x 13 cm.

• Price in first year of sale
• 13,500.00 ITL

• Mentioned in
• Catalogo ANIE (radio televisione elettroacustica 1971 1972)

• Author
• Model page created by Guglielmo Rebuffo. See "Data change" for further contributors.
