• Country
• United States of America (USA)

• Manufacturer / Brand
• Master-Craft Electronics Corp.; New York, NY

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 316736

• Number of Tubes
• 7

• Valves / Tubes
• 12DT8 12DT8 12BE6 12BA6 12BA6 12AV6 50C5

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: AM/FM 4 Speaker Radio Automatic Frequency Control 3YE 380 - Master-Craft Electronics Corp.

• Shape
• Tablemodel, with any shape - general.

• Notes

• Schematic may be similar to Star-Lite TMC-515.

  Made in Japan

• Author
• Model page created by Aldo Andreani. See "Data change" for further contributors.

• Other Models

• Here you find 20 models, 16 with images and 3 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Master-Craft Electronics Corp.; New York, NY
