National Panasonic FM/LW/MW/SW Radio Cassette Recorder RQ-551LJS
Panasonic, Matsushita, National ナショナル (also tubes); Osaka
- Country
- Japan
- Manufacturer / Brand
- Panasonic, Matsushita, National ナショナル (also tubes); Osaka
- Year
- 1984 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 203900
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 110; 125; 220; 240 / 4 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
- Power out
- 2.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: National Panasonic FM/LW/MW/SW Radio Cassette Recorder RQ-551LJS - Panasonic, Matsushita,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 365 x 225 x 105 mm / 14.4 x 8.9 x 4.1 inch
- Notes
-
Auto-stop function. Built-in electret microphone. Connectors for antenna, tape (rec/play), external microphone, headphone (8 ohms). Tuning and battery indicator.
Frequency ranges:
FM: 87.5 - 108 MHz
LW: 145 - 285 kHz
MW: 525 - 1605 KHz
SW: 5.9 - 18 MHz
- Net weight (2.2 lb = 1 kg)
- 3.8 kg / 8 lb 5.9 oz (8.37 lb)
- Author
- Model page created by Museum Roggenhofer. See "Data change" for further contributors.
