Stereo Receiver 758
Maximal (Marke? / brand?)
- Country
- Germany
- Manufacturer / Brand
- Maximal (Marke? / brand?)
- Year
- 1979 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 325872
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- 2SC1030 unknown_tr
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 70 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Receiver 758 - Maximal Marke? / brand?
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 620 x 115 x 320 mm / 24.4 x 4.5 x 12.6 inch
- Notes
-
Maximal 758 ist ein kombinierter AM/FM Rundfunk-Tuner und Verstärker, seine elektroakustischen Eigenschaften erfüllen oder übertreffen die HiFi-Norm DIN 45500 gemäss Aufdruck auf Vorder- und Rückseite (Stand etwa 1979).
7 Stationsspeicher-Sensorfelder für UKW. Anzeige für Abstimmung (Signalstärke) und Frequenz über Instrumente.
Hersteller/Manufacturer: Ekman & Co. Ltd. Japan
Distributor for Sweden: Ekman & Co. AB
- Net weight (2.2 lb = 1 kg)
- 10.9 kg / 24 lb 0.1 oz (24.009 lb)
- Mentioned in
- Stereo-HiFi-Handbook 1979 (Sweden)
- Author
- Model page created by Bjorn Hederstrom. See "Data change" for further contributors.
