Audio-Video-Funksender MBO FVS 1000

MBO Schmidt & Niederleitner GmbH & Co. KG; München

Data
Forum
Pictures
Collections

  • Year
  • 2001 ??
  • Category
  • Commercial Transmitter & Receiver (TRX not Amateur)
  • Radiomuseum.org ID
  • 306261

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Transceiver
  • Wave bands
  • Wave Bands given in the notes.
  • Details
  • Remote Control (with wire or wireless)
  • Power type and voltage
  • Powered by external power supply or a main unit. / DC: 9 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Audio-Video-Funksender MBO FVS 1000 - MBO Schmidt & Niederleitner
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 122 x 129 x 134 mm / 4.8 x 5.1 x 5.3 inch
  • Notes

  • Drahtloses Übertragungssystem für Audio- und Videosignale.

    Sendefrequenz: 2,4...2,4835 GHz, FM-moduliert, 4 Kanäle wählbar.
    Reichweite: bis 50 m in Gebäuden, bis 300 m im Freien.
    Rückkanal: 433,92 MHz für Übertragung von Signalen der IR-Fernbedienung zur Gerätefernsteuerung.
    Stromversorgung: 2x Netzadapter, 9 VDC, 300 mA.


  • Net weight (2.2 lb = 1 kg)
  • 0.246 kg / 0 lb 8.7 oz (0.542 lb)
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Michael Mischke. See "Data change" for further contributors.
